LITHIUM ION BATTERY APPLICATION

The best lithium ion deep cycle battery solution is the one that works for you.

send your inquiry

15Kwh Home Battery Storage

15kW energy storage system can better use renewable resources, such as wind and solar energy. And help reduce the use of electricity and provide greater flexibility and reliability for efficient power storage.

Battery System For Home

This battery storage system makes you better control your home power supply and improve reliability. It is a rechargeable system that is more convenient and keeps your home equipment running during power outages, switching to a style designed for the home. Higher capacity energy storage system that can work for company power.

Home Solar Battery System

Huanduy can provide you with an efficient and longer cycle life lithium-ion home solar battery system. It can operate parallel with utility power and provide the most reliable power for your home when the power supply fails or goes off-grid.

Bess Battery Energy Storage System

This bess battery energy storage system can install with communication functions. Provide you with a battery system to stay fully charged when you encounter a power outage in a harsh environment. And suitable for your office to provide backup power, efficient power, improves greater flexibility. It Makes you better reduce energy costs and improve efficiency.

Compact lithium-ion battery technology, able to quickly charge and discharge, more efficient solution to your backup power problems.

DETAILS

Solution1
Solution 2
Feature Listing
Battery module

Module modle 		51.2V50Ah
Battery type LiFePO4
Serial/Parallel 16S1P
Module dimension 530*420*161MM
Module weight 30KG
Number of modules 3PCS 4PCS 5PCS 6PCS
System parameters
Rated voltage 153.6V 204.8V 256V 307.2V
Working voltage range 110.4V-175.2V 147.2V-233.6V 184V-292V 220.8V-350.4V
Charge voltage 163.2V-165.6V 217.6V-220.8V 272V-276V 326.4V-331.2V
Floating charge voltage 160.8V-163.2V 214.4V-217.6V 268V-272V 321.6V-326.4V
Rated capacity 50Ah 50Ah 50Ah 50Ah
Energy 7.68Kwh 10.24Kwh 12.8Kwh 15.36Kwh
Rated charge current 25A
Peak charge current 50A
Rated discharge current 50A
Peak discharge current 100A
Charge temperature 0-55℃
Discharge temperature -10-55℃
Optimum temperature 15-25℃
Cooling method Natural cooling
Relative humidity 5%-95%
Altitude ≤2000M
Cycle Life ≥2000 cycles@80%DOD，0.5C/0.5C，25℃
Communication interfaces CAN2.0/RS485/Dry
Protection Over temperature, over current, over voltage, insulation and other multiple protection
Display LCD
Design lifetime ≥10 years
Certification UN38.3/UL1973/IEC62619
Dimension（L*W*H） 530*420*679MM 600*600*819MM 600*600*959MM 600*600*1099MM
Weight 110KG 140KG 170KG 200KG
Battery module
Module modle 51.2V50Ah
Battery type LiFePO4
Serial/Parallel 16S1P
Module dimension 530*420*161MM
Module weight 31.5KG
Number of modules 7PCS 8PCS 9PCS 10PCS
System parameters
Rated voltage 358.4V 409.6V 460.8V 512V
Working voltage range 257.6V-408.8V 294.4V-467.2V 331.2V-525.6V 368V-584V
Charge voltage 380.8V-386.4V 435.2V-441.6V 489.6V-496.8V 544V-552V
Floating charge voltage 375.2V-380.8V 428.8V-435.2V 482.4V-489.6V 536V-544V
Rated capacity 50Ah 50Ah 50Ah 50Ah
Energy 17.92Kwh 20.48Kwh 23.04Kwh 25.6Kwh
Rated charge current 25A
Peak charge current 50A
Rated discharge current 50A
Peak discharge current 100A
Charge temperature 0-55℃
Discharge temperature -10-55℃
Optimum temperature 15-25℃
Cooling method Natural cooling
Relative humidity 5%-95%
Altitude ≤2000M
Cycle Life ≥3500 cycles@80%DOD，0.5C/0.5C，25℃
Communication interfaces CAN2.0/RS485/Dry
Protection Over temperature, over current, over voltage, insulation and other multiple protection
Display LCD
Design lifetime ≥10 years
Certification UN38.3/UL1973/IEC62619
Dimension（L*W*H） 530*420*1239MM 600*600*1379MM 600*600*1519MM 600*600*1659MM
Weight 230KG 260KG 290KG 320KG
  • Modular design, standardized production, strong commonality, easy installation, operation and maintenance.
  • High consistency of internal resistance, voltage and capacity of single cell.
  • Intelligent system, low loss, high conversion efficiency, strong stability, reliable operation.
  • Support fast charging and discharging.
  • Perfect BMS protection function and control system, over current, over voltage, insulation and other multiple protection design.
  • The cycle times can reach more than 3500 times, the service life is more than 10 years, the comprehensive operation cost is low.
  • Visual LCD display allows you to set operating parameters, view real-time data and operating status, and accurately diagnose operating faults.
  • Supports communication protocol such as CAN2.0 and RS485, which can be used in various scenarios.
